Layout contents
Jumpers
Page
1. Clear RTC RAM (CLRTC1) 4-4
2. VGA controller setting (3-pin VGA_SW1) 4-5
3. LAN controller setting (3-pin LAN_SW1, LAN_SW2)
4-5
4. Baseboard Management Controller setting (3-pin BMC_EN1) 4-6
5. DMLAN setting (3-pin DM_IP_SEL1) 4-6
6. IPMI SW setting (3-pin IPMI_SW1) 4-7
7. Smart Ride Through jumper (3-pin SMART_PSU1) 4-7
Internal connectors
Page
1. Mini-SAS HD connector (ISATA1-2) 4-8
2. Slim PCIe connectors (SLIMPCIE1-2) 4-8
3. USB 3.2 Gen 1 connectors (SLIMUSB1)
4-9
4. Chassis Intrusion (2-pin INTRUSION1) 4-9
5. Front fan connectors (6-pin FRNT_FAN6-7) 4-10
6. Serial port connector (10-1 pin COM1) 4-11
7. TPM connector (20-1 pin TPM1) 4-11
8. M.2 (NGFF) card connector (NGFF1) 4-12
9. CRPS power connectors (PWR1-2) 4-13
10. MicroSD card slot (MSD1) 4-14
11. OCP3.0 Sideband Signal connector (10-pin OCP_SIDE1) 4-15
Onboard LEDs
Page
1. Standby Power LED (SBPWR1) 4-16
2. Baseboard Management Controller LED (BMCLED1) 4-16
3. Hard disk activity LED (HDDLED1)
4-17
4. Message LED (MESLED1) 4-17
5. Location LED (LOCLED1) 4-18
