Asus P8H77-M User Manual

1-9第一章：產品介紹
接口/跳線/插槽 頁數 接口/跳線/插槽 頁數
1. 中央處理器 / 機箱風扇電源插
槽（4-pin CPU_FAN、3-pin
CHA_FAN）
1-35 10. 電力指示燈（SB_PWR） 1-40
2. ATX 主板電源插槽（24-pin
EATXPWR、8-pin ATX12V）
1-36 11.
Intel
®
H77 Serial ATA 6.0Gb/s 設
備連接插座（7-pin SATA6G1-2
[灰色]）
1-31
3.
Intel
®
中央處理器插槽
1-10 12.
Intel
®
H77 Serial ATA 3.0Gb/s 設
備連接插座（7-pin SATA3G1-2
[藍色]）
1-32
4. DDR3 內存插槽 1-15 13. 系統控制面板連接排針
（10-1 pin PANEL）
1-37
5. TPM 連接排針（20-1 pin TPM）
1-38
14. USB 擴展套件數據線插槽（10-1
pin USB56、USB78、USB910）
1-33
6. MemOK! 按鈕 1-39 15. 串口連接插座 (10-1 pin COM1) 1-34
7. 內存指示燈 (DRAM_LED) 1-40 16. LPT 連接排針（26-1 pin LPT） 1-38
8. USB 3.0 擴展套件數據線插槽
(20-1 pin USB3_34)
1-33 17. 前面板音頻連接排針
（10-1 pin AAFP）
1-30
9. CMOS 配置數據清除（3-pin CLRTC） 1-28 18. 數字音頻連接排針
（4-1 pin SPDIF_OUT）
1-34
1.5.4 主板元件說明

Asus P8H77-M Specifications

General

ECC	No
Non-ECC	Yes
Memory voltage	1.5 V
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR3-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	1066, 1333, 1600, 1800, 1866, 2000, 2133, 2200 MHz
Supported memory module capacities	16GB, 1GB, 2GB, 4GB, 8GB
System bus rate	5 GT/s
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7
Maximum number of SMP processors	1
USB 2.0 connectors	3
Number of SATA III connectors	2
Number of Parallel ATA connectors	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	Realtek ALC887
Cooling type	Passive
Component for	PC
Power source type	ATX
Motherboard chipset	Intel H77
PC health monitoring	CPU, FAN, Temperature
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA II, SATA III
Cables included	SATA
Graphics card	HD Graphics
OpenGL version	3.2
DirectX version	11
Maximum resolution	2048 x 1536 pixels
Maximum graphics card memory	1696 MB
Parallel processing technology support	2-Way CrossFireX, LucidLogix Virtu, Quad-GPU CrossFireX
PCI Express slots version	2.0, 3.0
PCI Express configurations	1x4, 1x16
LAN controller	Realtek RTL8111F
Wi-Fi standards	Not supported
Networking features	Gigabit LAN
Ethernet interface type	Gigabit Ethernet
BIOS type	EFI AMI
ACPI version	2.0a
BIOS memory size	64 Mbit

Weight and Dimensions

Width	245 mm
