2-28 華碩 P8H77-M 主板用戶手冊
2.9 退出 BIOS 程序（Exit）
本菜單可讓您讀取 BIOS 程序出廠默認值與退出 BIOS 程序，並可存儲與取消對
BIOS 項目的更改。您可以從“Exit”菜單中進入 EZ 模式（EZ Mode）。
Load Optimized Defaults
本項目用來載入設置菜單中每個參數的默認值。選擇了該項目，或者按下 ＜F5＞
鍵後，系統會彈出一個確認視窗，點選 [Yes] 即可載入默認值。
Save Changes & Reset
完成設置後，在“Exit”菜單中選擇此項目以存儲您的設置。選擇了該項目，或者
按下 ＜F10＞ 鍵後，系統會彈出一個確認視窗，點選 [Yes] 即可存儲變更並退出。
Discard Changes & Exit
本項目可放棄您所做的更改，並退出 BIOS 設置程序。選擇了該項目，或者按下
＜Esc＞ 鍵後，系統會彈出一個確認視窗，點選 [Yes] 即可放棄變更並退出。
ASUS EZ Mode
本項目用來進入 EZ 模式（EZ Mode）畫面。
Launch EFI Shell from filesystem device
本項目用來開啟可用文件系統裝置中的 EFI Shell 應用程序（shellx64.efi）。
Exit
Load Optimized Defaults
Save Changes & Reset
Discard Changes & Exit
ASUS EZ Mode
Launch EFI Shell from lesystem device

Asus P8H77-M Specifications

General

ECC	No
Non-ECC	Yes
Memory voltage	1.5 V
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR3-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	1066, 1333, 1600, 1800, 1866, 2000, 2133, 2200 MHz
Supported memory module capacities	16GB, 1GB, 2GB, 4GB, 8GB
System bus rate	5 GT/s
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7
Maximum number of SMP processors	1
USB 2.0 connectors	3
Number of SATA III connectors	2
Number of Parallel ATA connectors	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	Realtek ALC887
Cooling type	Passive
Component for	PC
Power source type	ATX
Motherboard chipset	Intel H77
PC health monitoring	CPU, FAN, Temperature
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA II, SATA III
Cables included	SATA
Graphics card	HD Graphics
OpenGL version	3.2
DirectX version	11
Maximum resolution	2048 x 1536 pixels
Maximum graphics card memory	1696 MB
Parallel processing technology support	2-Way CrossFireX, LucidLogix Virtu, Quad-GPU CrossFireX
PCI Express slots version	2.0, 3.0
PCI Express configurations	1x4, 1x16
LAN controller	Realtek RTL8111F
Wi-Fi standards	Not supported
Networking features	Gigabit LAN
Ethernet interface type	Gigabit Ethernet
BIOS type	EFI AMI
ACPI version	2.0a
BIOS memory size	64 Mbit

Weight and Dimensions

Width	245 mm
