華碩 P8H77-M 主板用戶手冊1-10
1.6 中央處理器 (CPU)
本主板配備一組中央處理器插槽，是專為 LGA1155 腳位封裝的 Intel
®
第二代/第
三代 Core™ i7 / Core™ i5 / Core™ i3 / Pentium
®
/ Celeron
®
處理器所設計。
在安裝中央處理器之前，請確認所有的電源連接都已拔除。
• 在您購買本主板之後，請確認在 LGA1155 插座上附有一個即插即用的
保護蓋，並且插座接點沒有彎曲變形。若是保護蓋已經損壞或是沒有保
護蓋，或者是插座接點已經彎曲，請立即與您的經銷商聯絡。
•
在安裝完主板之後，請將即插即用的保護蓋保留下來。只有 LGA1155
插槽上 附 有 即 插 即 用 保護蓋 的 主 板 符 合 R e t u rn M erc h a n d i s e
Authorization（RMA）的要求，華碩電腦才能為您處理產品的維修與
保修。
•本保修不包括處理器插座因遺失、錯誤的安裝或不正確地移除即插即用
保護蓋所造成的損壞。

Asus P8H77-M Specifications

General

ECC	No
Non-ECC	Yes
Memory voltage	1.5 V
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR3-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	1066, 1333, 1600, 1800, 1866, 2000, 2133, 2200 MHz
Supported memory module capacities	16GB, 1GB, 2GB, 4GB, 8GB
System bus rate	5 GT/s
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7
Maximum number of SMP processors	1
USB 2.0 connectors	3
Number of SATA III connectors	2
Number of Parallel ATA connectors	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	Realtek ALC887
Cooling type	Passive
Component for	PC
Power source type	ATX
Motherboard chipset	Intel H77
PC health monitoring	CPU, FAN, Temperature
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA II, SATA III
Cables included	SATA
Graphics card	HD Graphics
OpenGL version	3.2
DirectX version	11
Maximum resolution	2048 x 1536 pixels
Maximum graphics card memory	1696 MB
Parallel processing technology support	2-Way CrossFireX, LucidLogix Virtu, Quad-GPU CrossFireX
PCI Express slots version	2.0, 3.0
PCI Express configurations	1x4, 1x16
LAN controller	Realtek RTL8111F
Wi-Fi standards	Not supported
Networking features	Gigabit LAN
Ethernet interface type	Gigabit Ethernet
BIOS type	EFI AMI
ACPI version	2.0a
BIOS memory size	64 Mbit

Weight and Dimensions

Width	245 mm
