1-27第一章:產品介紹
是否支持 PCIe 3.0 的傳輸速率因處理器類型而異,且需安裝 PCIe 3.0
顯卡。
VGA 卡模式時,建議您將 PCI Express x16 顯卡安裝在 PCIe 3.0/2.0
x16_1 插槽(藍色)以獲得更好性能。
在運 CrossFireX™ 模式時,建議您將 PCI Express x16 卡安裝
PCIe 3.0/2.0 x16_1 插槽與 PCIe 2.0 x16_2 插槽,以獲得更好性
能。
使
CHA_FAN以取得更好的散熱性能
VGA 設置
PCI Express 運行模式
PCIe 3.0/2.0 x16_1 PCIe 2.0 x16_2
一張 VGA/PCIe
x16(安裝單張 VGA 卡時建
議使用)
兩張 VGA/PCIe
x16 x4
1.8.6 PCI Express 3.0 x16 擴展卡插槽
本主板配備一個 PCI Express 3.0 x16 插槽,可支持 PCI Express 3.0 x16 規格的
顯卡以及其它符合 PCI Express 規格的功能擴展卡。
1.8.7 指定中斷要求
標準指定中要求
A B C D E F G H
PCIex16_1 共享
PCIex16_2 共享
PCIex1_1 共享
PCI_1 共享
LAN 共享
VGA 共享
USB 2.0 控制器 1 共享
USB 2.0 控制器 2 共享
XHCI 控制器 共享
SATA 控制器 1 共享
SATA 控制器 2 共享
HD 音頻 共享
