第二章：BIOS 信息 2-23
2.6 監控菜單（Monitor）
本菜單顯示系統溫度/電源狀態，並可用來變更風扇設置。
2.6.1 CPU Temperature / MB Temperature [xxxºC/xxxºF]
本主板具備了中央處理器 / 主板的溫度感測器，可自動檢測並顯示目前處理器的溫
度。若您不想顯示檢測到的溫度，請選擇 [Ignored]。
2.6.2 CPU / Chassis Fan Speed [xxxx RPM] 或 [Ignore] / [N/A]
主板具備中央處理器 / 機箱風扇轉速 RPM（Rotations Per Minute）監控功能。
如果主板上沒有連接風扇，這裡會顯示 [N/A]。若您不想顯示檢測到的速度，請選擇
[Ignored]。
2.6.3 CPU Voltage, 3.3V Voltage, 5V Voltage, 12V Voltage
本主板具有電壓監控的功能，用來確保主板以及 CPU 接受正確的電壓準位，以及穩
定的電流供應。若您不想檢測此項目，請選擇 [Ignored]。
往下滾動顯示以下項目：
Main
Ai Tweaker
Advanced Monitor Boot Tool
Exit
Version 2.10.1208. Copyright (C) 2012 American Megatrends, Inc.
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Shortcut
F5: Optimized Defaults
F10: Save ESC: Exit
F12: Print Screen
UEFI BIOS Utility - Advanced Mode
CPU Temperature +45ºC / +113ºF
MB Temperature +34ºC / +93ºF
CPU Fan Speed 3325 RPM
Chassis Fan Speed N/A
CPU Voltage +1.184 V
3.3V Voltage +3.312 V
5V Voltage +5.080 V
12V Voltage +12.192 V
CPU Q-Fan Control Enabled
CPU Fan Speed Low Limit 200 RPM
CPU Fan Prole Standard
Chassis Fan Speed Low Limit 600 RPM
Version 2.10.1208. Copyright (C) 2012 American Megatrends, Inc.
Anti Surge Support Enabled

Asus P8H77-M Specifications

General

ECC	No
Non-ECC	Yes
Memory voltage	1.5 V
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR3-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	1066, 1333, 1600, 1800, 1866, 2000, 2133, 2200 MHz
Supported memory module capacities	16GB, 1GB, 2GB, 4GB, 8GB
System bus rate	5 GT/s
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7
Maximum number of SMP processors	1
USB 2.0 connectors	3
Number of SATA III connectors	2
Number of Parallel ATA connectors	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	Realtek ALC887
Cooling type	Passive
Component for	PC
Power source type	ATX
Motherboard chipset	Intel H77
PC health monitoring	CPU, FAN, Temperature
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA II, SATA III
Cables included	SATA
Graphics card	HD Graphics
OpenGL version	3.2
DirectX version	11
Maximum resolution	2048 x 1536 pixels
Maximum graphics card memory	1696 MB
Parallel processing technology support	2-Way CrossFireX, LucidLogix Virtu, Quad-GPU CrossFireX
PCI Express slots version	2.0, 3.0
PCI Express configurations	1x4, 1x16
LAN controller	Realtek RTL8111F
Wi-Fi standards	Not supported
Networking features	Gigabit LAN
Ethernet interface type	Gigabit Ethernet
BIOS type	EFI AMI
ACPI version	2.0a
BIOS memory size	64 Mbit

Weight and Dimensions

Width	245 mm
