2-26 華碩 P8H77-M 主板用戶手冊
2.7.4 Option ROM Messages [Force BIOS]
[Force BIOS] 在啟動過程中，第三方 ROM 信息將會強制顯示。
[Keep Current] 只有當第三方廠商將裝置設置為顯示 ROM 信息時，第三方 ROM 信
息才會顯示。
2.7.5 Setup Mode [EZ Mode]
[Advanced Mode] 將高級模式（Advanced Mode）畫面設為進入 BIOS 設置程序
的默認畫面。
[EZ Mode] 將 EZ 模式（EZ Mode）畫面設為進入 BIOS 設置程序的默認畫
面。
2.7.6 UEFI/Legacy Boot [Enable both UEFI and Legacy]
[Enable both UEFI and Legacy] 同時開啟 UEFI 和 Legacy 啟動。
[Disable UEFI] 開啟 Legacy 啟動，關閉 UEFI 啟動。
[Disable Legacy] 開啟 UEFI 啟動，關閉 Legacy 啟動。
2.7.7 PCI ROM Priority [Legacy ROM]
本項目讓您選擇當存在多個 Option ROM 時，選擇哪個 PCI Option ROM 來啟
動。設置值有：[Legacy ROM] [EFI Compatible ROM]。
2.7.8 啟動項目順序（Boot Option Priorities）
本項目讓您自行選擇啟動磁盤並排列開機裝置順序。屏幕上顯示的裝置數量依據
系統中安裝的裝置而定。
• 要選擇系統開機的啟動裝置，請在 ASUS 的圖標出現時按下 ＜F8＞。
• 要以安全模式進入 Windows
®
操作系統，請在開機自檢完成後，按下
＜F8＞。
2.7.9 Boot Override
本項目顯示可用裝置。屏幕上顯示的裝置數量依據系統中安裝的裝置而定。選擇
一個項目，從該裝置啟動。

Asus P8H77-M Specifications

General

ECC	No
Non-ECC	Yes
Memory voltage	1.5 V
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR3-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	1066, 1333, 1600, 1800, 1866, 2000, 2133, 2200 MHz
Supported memory module capacities	16GB, 1GB, 2GB, 4GB, 8GB
System bus rate	5 GT/s
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7
Maximum number of SMP processors	1
USB 2.0 connectors	3
Number of SATA III connectors	2
Number of Parallel ATA connectors	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	Realtek ALC887
Cooling type	Passive
Component for	PC
Power source type	ATX
Motherboard chipset	Intel H77
PC health monitoring	CPU, FAN, Temperature
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA II, SATA III
Cables included	SATA
Graphics card	HD Graphics
OpenGL version	3.2
DirectX version	11
Maximum resolution	2048 x 1536 pixels
Maximum graphics card memory	1696 MB
Parallel processing technology support	2-Way CrossFireX, LucidLogix Virtu, Quad-GPU CrossFireX
PCI Express slots version	2.0, 3.0
PCI Express configurations	1x4, 1x16
LAN controller	Realtek RTL8111F
Wi-Fi standards	Not supported
Networking features	Gigabit LAN
Ethernet interface type	Gigabit Ethernet
BIOS type	EFI AMI
ACPI version	2.0a
BIOS memory size	64 Mbit

Weight and Dimensions

Width	245 mm
