1-31第一章：產品介紹
2. Intel
®
H77 Serial ATA 6.0Gb/s 設備連接插座（7-pin SATA6G1-2 [灰色]）
這些插槽支持使用 Serial ATA 6.0Gb/s 數據線連接 Serial ATA 6.0Gb/s 硬盤
或光驅。
若您安裝了 Serial ATA 硬盤，您可以通過 Intel
®
Rapid Storage 技術，與內
置的 Intel
®
H77 芯片組來創建 RAID 0、RAID 1、RAID 5 以及 RAID 10 磁盤
陣列。
SA
TA
6G_2
G
N
D
R
S
A
T
A
_T
X
P
2
R
S
A
T
A
_
TX
N
2
G
N
D
R
S
A
T
A
_R
X
N
2
R
S
A
T
A
_
R
X
P
2
G
N
D
SA
TA
6G_1
G
N
D
R
S
A
T
A
_
T
X
P
1
R
S
A
T
A
_
TX
N
1
G
N
D
R
S
A
T
A
_
R
X
N
1
R
S
A
T
A
_
R
X
P
1
G
N
D
P8H77-M
P8H77-M Intel
®
SATA 6.0Gb/s connectors
• 這些插槽的默認值為 [AHCI Mode]，若您想要使用這些插槽來建構 Serial
ATA RAID 功能，請將 BIOS 程序中的 SATA Mode 項目設置為 [RAID
Mode]。請參考 2.5.3 SATA 設置（SATA Configuration） 一節的詳細
說明。
• 當您使用支持 NCQ 技術的硬盤時，請將 BIOS 程序中的 SATA Mode 設
置為 [AHCI Mode]。請參考 2.5.3 SATA 設置（SATA Configuration）
一節的說明。
• 使用 Serial ATA 硬盤之前，請先安裝 Windows
®
XP Service Pack 3 或更
新版本的操作系統。Serial ATA RAID 功能只有在操作系統為 Windows
®
XP SP3 或更新的版本時才能使用。

Asus P8H77-M Specifications

General

ECC	No
Non-ECC	Yes
Memory voltage	1.5 V
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR3-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	1066, 1333, 1600, 1800, 1866, 2000, 2133, 2200 MHz
Supported memory module capacities	16GB, 1GB, 2GB, 4GB, 8GB
System bus rate	5 GT/s
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7
Maximum number of SMP processors	1
USB 2.0 connectors	3
Number of SATA III connectors	2
Number of Parallel ATA connectors	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	Realtek ALC887
Cooling type	Passive
Component for	PC
Power source type	ATX
Motherboard chipset	Intel H77
PC health monitoring	CPU, FAN, Temperature
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA II, SATA III
Cables included	SATA
Graphics card	HD Graphics
OpenGL version	3.2
DirectX version	11
Maximum resolution	2048 x 1536 pixels
Maximum graphics card memory	1696 MB
Parallel processing technology support	2-Way CrossFireX, LucidLogix Virtu, Quad-GPU CrossFireX
PCI Express slots version	2.0, 3.0
PCI Express configurations	1x4, 1x16
LAN controller	Realtek RTL8111F
Wi-Fi standards	Not supported
Networking features	Gigabit LAN
Ethernet interface type	Gigabit Ethernet
BIOS type	EFI AMI
ACPI version	2.0a
BIOS memory size	64 Mbit

Weight and Dimensions

Width	245 mm
