第二章：BIOS 信息 2-5
Are you sure to update BIOS?
Yes No
D:\>bupdater /pc /g
升級 BIOS 文件
請依照以下步驟用 BIOS Updater 工具程序升級 BIOS 文件：
1. 在 FreeDOS 提示符後輸入
bupdater /pc /g 並按下 ＜Enter＞。
2. BIOS Updater 畫面出現，如下圖。
3. 按下 ＜Tab＞ 鍵在各設置欄之間切換，接著用 ＜Up/Down/Home/End＞ 鍵來
選擇 BIOS 文件並按下 ＜Enter＞。BIOS Updater 會檢查您所選擇的 BIOS 文件
並提示您確認是否要升級 BIOS。
4. 選擇 [Yes] 並按下 ＜Enter＞。當 BIOS 升級完畢後，按 ＜ESC＞ 退出 BIOS
Updater。重新啟動您的電腦。
當升級 BIOS 時，請勿關閉或重置系統！若是這麼做，將可能導致系統
開機失敗。
• 對於 BIOS Updater 1.04 或更高版本，當 BIOS 升級完畢後，工具程序
會自動回到 DOS 畫面。
• BIOS 程序的出廠默認值可讓系統運行處於最佳性能。若系統因您改變
BIOS 程序而導致不穩定，請讀取出廠默認值來保持系統的穩定。請
在 Exit 菜單中選擇【Load Optimized Defaults】項目。詳細說明請參
考“2.9 退出 BIOS 程序”一節。
• 若您之前移除了所有 SATA 硬盤，當 BIOS 升級完成後，請確認將所有
SATA 硬盤重新連接到主板。
ASUSTek BIOS Updater for DOS V1.30
Current ROM
Update ROM
A:
Note
[Enter] Select or Load [Tab] Switch [V] Drive Info
[Up/Down/Home/End] Move [Esc] Exit
P8H77M.CAP 8390656 2012-02-15 17:30:48
PATH: A:\
BOARD: P8H77-M
VER: 0230
DATE: 02/14/2012
BOARD: Unknown
VER: Unknown
DATE: Unknown

Asus P8H77-M Specifications

General

ECC	No
Non-ECC	Yes
Memory voltage	1.5 V
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR3-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	1066, 1333, 1600, 1800, 1866, 2000, 2133, 2200 MHz
Supported memory module capacities	16GB, 1GB, 2GB, 4GB, 8GB
System bus rate	5 GT/s
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7
Maximum number of SMP processors	1
USB 2.0 connectors	3
Number of SATA III connectors	2
Number of Parallel ATA connectors	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	Realtek ALC887
Cooling type	Passive
Component for	PC
Power source type	ATX
Motherboard chipset	Intel H77
PC health monitoring	CPU, FAN, Temperature
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA II, SATA III
Cables included	SATA
Graphics card	HD Graphics
OpenGL version	3.2
DirectX version	11
Maximum resolution	2048 x 1536 pixels
Maximum graphics card memory	1696 MB
Parallel processing technology support	2-Way CrossFireX, LucidLogix Virtu, Quad-GPU CrossFireX
PCI Express slots version	2.0, 3.0
PCI Express configurations	1x4, 1x16
LAN controller	Realtek RTL8111F
Wi-Fi standards	Not supported
Networking features	Gigabit LAN
Ethernet interface type	Gigabit Ethernet
BIOS type	EFI AMI
ACPI version	2.0a
BIOS memory size	64 Mbit

Weight and Dimensions

Width	245 mm
