4. Installtheexpansioncardto
thebracket(A)andsecurethe
expansioncardwiththescrew
removedinstep3(B).
5. Installtheexpansioncardtothe
risercard(C).
6. Installtheexpansioncardandthe
risercardassemblyintothePCIE
connectoronthemotherboard(D).
Enusre that the golden connectors
oftherisercardareseatedrmlyin
place.
7. Securethebracketusingthescrew
removed in step 2.
