Asus RS100-E9-P12 - Expansion Card; Installing an Expansion Card

Chapter 2: Hardware Information
2-26
2. Removethescrewtoreleasethe
expansioncardbracketfromthe
chassis.
Toinstalltheexpansioncard:
1. Hold the riser card and pull it upwards
todetachitfromthePCIExpressslot
onthemotherboard.
3. Removethescrewfromthemetal
cover(A)andremovethemetalcover
(B)fromthebracket.
2.5 Expansion card
Thissystemcomeswitharisercard.Youneedtoremovetherisercardandtheexpansion
slotbracketifyouwanttoinstallanexpansioncard.
Unplugthepowercordbeforeinstallingorremovinganexpansioncard.Failuretodoso
maycauseseveredamagetothemotherboardandothersystemcomponents!
2.5.1 Installing an expansion card
