Asus RS100-E9-P12 - Internal Connectors

ASUS RS100-E9-PI2
4-17
TheactualdatatransferratedependsonthespeedofSerialATAharddisksinstalled.
4.5.3 Internal connectors
1. Serial ATA 6.0 Gbps connectors (7-pin SATA 6Gbps_1-4 connectors [Light Blue];
7-pin SATA 6Gbps_5-6 connectors [Gray])
SupportedbytheIntel
®
C232chipset,theseconnectorsarefortheSerialATAsignal
cablesforSerialATAharddiskdrivesthatallowsupto6Gb/sofdatatransferrate.
IfyouinstalledSerialATAharddiskdrives,youcancreateaRAID0,RAID1,RAID10,
orRAID5conguration.
2. Hard disk activity LED connector (4-pin HDLED1)
ThisLEDconnectorisforthestorageadd-oncardcableconnectedtotheSATAor
SASadd-oncard.ThereadorwriteactivitiesofanydeviceconnectedtotheSATAor
SASadd-oncardcausesthefrontpanelLEDtolightup.
