ASUS Z10PH-D16
2-17
4. AlignandinserttherisercardandexpansioncardassemblyintothePCI-Eslotonthe
motherboard.
Theexpansioncardtsinoneorientationonly.Ifitdoesnott,tryreversingit.
5. Replace the system cover.
riser card and expansion card assembly
PCI-E x24 slot
