ASUS Z10PH-D16
2-31
6. M.2 (NGFF) connector (NGFF1)
ThisconnectorallowsyoutoinstallanM.2device.
• Thisconnectorsupportstype2242devicesonbothSATAandPCI-Einterface.
• PleaserefertothefollowingguidelinesininstallinganM.2device:
-
For SATA Interface:
ConnecttheFP_SATA7(lightgray)porttoanyofthe 
  onboardSATAports(SATA1-6)oranySATAportfromtheadd-onstoragecard
  usingaSATAcable.
- For PCIE Interface:
YouneedtoinstallasecondCPU(onCPU2)tosupportthis
function.
TheM.2(NGFF)deviceispurchasedseparately
