Asus Z10PH-D16 - Thermal Sensor Cable Connectors (3-Pin TR1); Trusted Platform Module Connector (20-1 Pin TPM1)

2-30
Chapter 2: Hardware information
4. Thermal sensor cable connectors (3-pin TR1)
Thisconnectorisfortemperaturemonitoring.Connectthethermalsensorcablesto
theseconnectorsandplacetheotherendstothedevices,whichyouwanttomonitor
temperature.
GotoBIOSsetuptochangethedefaultsettingofTR1from“Disabled“to“Enabled“
before using the thermal sensor cable.
5. Trusted Platform Module connector (20-1 pin TPM1)
ThisconnectorsupportsaTrustedPlatformModule(TPM)system,whichcansecurely
storekeys,digitalcerticates,passwords,anddata.ATPMsystemalsohelpsenhance
networksecurity,protectsdigitalidentities,andensuresplatformintegrity.
