Asus Z10PH-D16 - Internal Connectors; Internal Connectors Page; Serial ATA 6.0 Gb;S Connectors (7-Pin SATA1-6 [Light Blue])

2-28
Chapter 2: Hardware information
TheactualdatatransferratedependsonthespeedofSerialATAharddisksinstalled.
2.7.2 Internal connectors
1. Serial ATA 6.0 Gb/s connectors (7-pin SATA1-6 [Light blue])
TheseconnectorsarefortheSerialATAsignalcablesforSerialATAharddiskdrives.
Theseconnectorscanalsobeusedwiththegoldenngerdesignofthemotherboard
usingaSATAcable.Formoreinformation,refertothe
Z10PH-D16 Golden Finger
section of this user guide.
IfyouinstalledSerialATAharddiskdrives,youcanuseasoftwareRAIDsolutionto
createaRAID0,RAID1,RAID5,oraRAID10conguration.Formoreinformation
ontheSATARAIDsolutionssupportedonthismotherboard,refertothe
RAID
Configuration
chapter of this user guide.
