Rubber Track Loader
8. Loader/Transmission Controls Disassembly and Assembly
8-4
Loader Float Magnet Installation
Position
Magnet
Figure 8-12
1. Position the loader float magnet at the front of
the control.
Install
Screw
Figure 8-13
2. The loader float magnet is held in place by an
allen screw at the bottom of the magnet. Install
this screw.
Loader Float
Magnet
Figure 8-14
3. With the loader float magnet installed, the con-
trol is ready to mount in the console.
4. Position the control on the console and pull the
rubber boot down over the base of the joystick.
5. Re-attach the plastic console.
