Rubber Track Loader
9. Transmission and Drive Disassembly and Assembly
9-5
Figure 9-13
Tandem Pump Installation
1. Install the mounting bolts (with spring lock washer
and flat washer) on the tandem pump, at 85 ft.-lb.
with blue loctite.
Figure 9-14
Figure 9-15
2. Install the hoses and tubes on the tandem pump.
Hydraulic Reservoir Clean-out
If there has been a pump failure it is necessary to
clean out the hydraulic reservoir, as well has hoses,
tubes and hydraulic lines.
Figure 9-16
Figure 9-17
Pump shaft
Install
Bolt
