Owner Installation Instructions DCB-05V2 Gate Controller 21
Parameter Min Max Default Step Unit Menu Section
Menu 5 - Light Times
ON AFTER CYCLE LIGHT TIME - Time light remains on for after a
cycle
0 255 60 1 Sec 5.1 14.2
ON BEFORE OPEN CYCLE LIGHT TIME
Minimum time light is activated for prior to opening
0 255 0 1 Sec 5.2 14.2
ON BEFORE CLOSE CYCLE LIGHT TIME
Minimum time light is activated for prior to closing
0 255 0 1 Sec 5.3 14.2
Menu 6 - Motor Settings
CLOSE SYNC DELAY TIME
Time delay between M2 and M1 closing
0.0 25.5 2.0 0.1 SEC 6.1 Appendix C
OPEN SYNC DELAY TIME
Time delay between M1 and M2 opening
0.0 25.5 2.0 0.1 SEC 6.2
OPEN SPEED VOLTS
Voltage applied to motors when opening
12 24 22 1 VOLTS 6.3
CLOSE SPEED VOLTS
Voltage applied to motors when closing
12 24 20 1 VOLTS 6.4
SLOW SPEED VOLTS
Voltage applied to motors when slowing down
6 24 8 1 VOLTS 6.5
SLOW TIME
The time between slow down and end of cycle
0.1 10.0 3.0 0.1 SEC 6.6
HOMING / SETUP SPEED VOLTS
Voltage applied to motors when setting up the travel limits
12 24 Norm 1 Volts 6.7
STOP PAUSE TIME
Pause time used between motor direction changes
0.0 2.0 0.3 0.1 SEC 6.8
M1 NORMAL OPEN TIME
Normal open time for motor 1
0.0 60.0 0.0 0.1 SEC 6.9
M1 NORMAL CLOSE TIME
Normal close time for motor 1
0.0 60.0 0.0 0.1 SEC 6.10
M2 NORMAL OPEN TIME
Normal open time for motor 2
0.0 60.0 0.0 0.1 SEC 6.11
M2 NORMAL CLOSE TIME
Normal close time for motor 2
0.0 60.0 0.0 0.1 SEC 6.12
M1 CLOSE DELAY
Close Delay for Motor 1
0.0 25.5 0.0 0.1 SEC 6.13
MAX OVERRUN TIME
Extra time allowed for cycle to complete (beyond normal cycle time)
0 60 5 1 6.14
A - Console Menu Structure
Appendix
Parameter Min Max Default Menu Section
Menu 7 - Operating Modes
SB1 TYPE 2 WIRE
3 WIRE
2 WIRE
3 WIRE
7.1 Appendix C
SB2 TYPE 2 WIRE
3 WIRE
2 WIRE
3 WIRE
7.2 Appendix C
SB1 INPUT MODE
Sets the Input mode for Safety Beam 1.
Only one option can be selected.
NOT USED,
CLS TO REV
CLS TO STOP
OPN/CLS TO
STOP
OPEN INPUT
SWIPE INPUT
CLOSE INPUT
PED INPUT
DISABLED
NOT USED,
CLS TO REV
CLS TO STOP
OPN/CLS TO STOP
OPEN INPUT
SWIPE INPUT
CLOSE INPUT
PED INPUT
DISABLED On
NOT USED 7.3 Appendix C
SB2 INPUT MODE
Sets the Input mode for Safety Beam 2.
Only one option can be selected.
NOT USED,
CLS TO REV
CLS TO STOP
OPN/CLS TO
STOP
OPEN INPUT
SWIPE INPUT
CLOSE INPUT
PED INPUT
DISABLED
NOT USED,
CLS TO REV
CLS TO STOP
OPN/CLS TO STOP
OPEN INPUT
SWIPE INPUT
CLOSE INPUT
PED INPUT
DISABLED On
NOT USED 7.4 Appendix C
PED INPUT = SWIPE MODE Selects PED input
functions as pedestrian access swipe input
Off On Off 7.5 Appendix C
OPN INPUT N/C OPERATION
Selects operating polarity of OPN input
Off On Off 7.6 Appendix C
STP INPUT N/C OPERATION
Selects operating polarity of STP input
Off On Off 7.7 Appendix C
AUX INPUT OPERATION LIGHT
MOTOR
ENGAGED
LIGHT
MOTOR ENGAGED
LIGHT 7.8 Appendix C
VACATION MODE
Selects vacation mode - disables remote control
Off On Off 7.9 Appendix C
REMOTE CODE ENABLED
Selects remote transmitter coding function
On Off On 7.10 Appendix C
BATTERY/SOLAR MODE
Selects Battery Backup/Solar operation
BATTERY
ENABLED
SOLAR ENABLED
BATTERY ENABLED
SOLAR ENABLED
BATTERY
ENABLED
7.11 Appendix C
PASSWORD
Selects password protection for all changes
Off On
Off 7.12 Appendix C
TX # GROUPING
Selects transmitter number group display for
mat.
Off On Off 7.13 Appendix C
OUTPUTS 1 MODE
Selects function of OUTPUT1
LOCK DRIVE
LIGHT DRIVE
3 WIRE SB 0V
NOT USED
LOCK DRIVE
LIGHT DRIVE
3 WIRE SB 0V
NOT USED
7.14 Appendix C
OUTPUTS 2 MODE
Selects function of OUTPUT2
LOCK DRIVE
LIGHT DRIVE
3 WIRE SB 0V
NOT USED
LOCK DRIVE
LIGHT DRIVE
3 WIRE SB 0V
NOT USED
7.15 Appendix C
FAULT AUTO RESET Off On Off 7.16 Appendix C
SBFEC MODE AVAILABLE
DISABLED
AVAILABLE
DISABLED
AVAILABLE 7.17 Appendix C
To Next Page
