Atag XL75W User Manual

15
Product description
ATAG XL W Cascade accessories
FG codes Description Single Boiler Cascade
WH
in line
Cascade
WH
B2B
Power
size
75 105 150 180 210
3905101 MIN. GAS PRESSURE SWITCH - BOILER x x x x x x
3905102 MIN. GAS PRESSURE SWITCH - CASCADE x x 0-1600
3905103 ROOM FAN + EXT. GAS VALVE x x x x x x
3905104 GAS FILTER 70-100-140 x x x x
3905105 GAS FILTER 170-200 x x x
3905108 TAE/TAS GAS VALVE kit BOILER CH x
3905109 TAE/TAS GAS VALVE kit BOILER DHW x
3905107 TAE/TAS GAS VALVE CONNECTION KIT WH CH FRONT x 0-1600
3905110 TAE/TAS GAS VALVE CONNECTION KIT WH CH BACK x 0-1600
3905111 TAE/TAS GAS VALVE CONNECTION KIT WH DHW x 0-1600
3905115 AIR FILTER Ø100 x x x x
3905116 AIR FILTER Ø130 x x x
3905117 WATER-GAS CONNECTION KIT x x x x x x
3905118 LPG kit 70 x x x x
3905119 LPG kit 100 x x x x
3905120 REMOCON MODBUS-LON x x x x x x x x 0-1600
3905121 REMOCON MODBUS-BACNET x x x x x x x x 0-1600
3905122 REMOCON MODBUS x x x x x x x x 0-1600
3905123 REMOCON MODBUS-KNX x x x x x x x x 0-1600
3905124 CLIP IN ZONE MANAGER x x x x x x x x 0-1600
3905045 Low loss header-DHW sensor x x x x x x x x 0-1600
3905127 Outdoor sensor x x x x x x x x 0-1600
3905128 Zone sensor x x x x x x x x 0-1600
3905129 COLLECTOR FLOW/RETURN DN65 2B LINE / 4B B2B x x 0-465
3905130 COLLECTOR FLOW/RETURN DN65 3B LINE / 6B B2B x x 0-465
3905131 GAS PIPE DN65 DUO x x 0-1600
3905132 COLLECTOR FLOW/RETURN DN100 2B LINE / 4B B2B x x 0-1600
3905134 COLLECTOR FLOW/RETURN DN100 3B LINE / 6B B2B x x 0-1600
3905136 INSULATION COLLECTOR DN65/DN100 (L=1B) x x 0-1600
3905137 CASCADE DEAREATOR x x 0-1600
3905138 GAS FILTER DN65 x x 0-1600
3905026 FLANGE KIT DN65 WATER x x 0-465
3905027 FLANGE KIT DN100 WATER x x 0-1600
3905029 FLANGE KIT DN65 GAS x x 0-1600
3905125 ZHOGLQJÀDQJH'1ZDWHU'1JDV x x 0-465
3905038 LASFLENS SET DN100 A/R + GAS DN 65 x x 0-1600
3905126 ZHOGLQJÀDQJH'1ZDWHU'1JDV x x 0-1600
3905142 FRAME FOOT L-SHAPE x 0-1600
3905143 FRAME FOOT I SHAPE x 0-1600
3905144 UPPER HORIZONTAL - LOWER SPACER SUPPORT 2B x x 0-1600
3905147 UPPER HORIZONTAL - LOWER SPACER SUPPORT 3B x x 0-1600
3905148 MOUNTING BRACKET 2B x x 0-1600
3905149 MOUNTING BRACKET 3B x x 0-1600
3905167 INSULATION CONN KIT WALL HUNG x x 0-1600
3905173 BOILER Low loss header dT10-20K x x x x x x
3905175 Insulation BOILER Low loss header dT10-20K x x x x x x
3905033 Low loss header DN65 x x 0-465
3905034 Low loss header DN100 x x 0-960
3905035 Bend 90° DN65 x x 0-465
3905041 Bend 90° DN65 insulation x x 0-465
3905036 Bend 90° DN100 x x 0-1600
3905174 Insulation Bend 90° DN100 x x 0-1600
3905176 Low loss header DN100 DUO kit x x 960-1600
3905040 Insulation LLH header DN65 x x 0-465
3905177 Insulation LLH header DN100 x x 0-960
3905186 BOILER SE Plate HEAT EXCH. dT10K x x x
3905187 BOILER DE Plate HEAT EXCH. dT10K x x x x
3905188 BOILER SE Plate HEAT EXCH. dT15K x x x
3905189 BOILER DE Plate HEAT EXCH. dT15K x x x x
3905190 BOILER SE Plate HEAT EXCH. dT20K x x x
3905191 BOILER DE Plate HEAT EXCH. dT20K x x x x
