Atag XL75W User Manual

23
Installation
Cascade free-standing back-to-back
 3RVLWLRQWKHÀRZDQGUHWXUQKHDGHU
in the required location. When using
VHYHUDOÀRZDQGUHWXUQKHDGHUV
FRQQHFWWKHÀRZDQGUHWXUQKHDGHUV
with the supplied gaskets, M12
(DN65) or M16 (DN100) bolts,
spring washers and nuts. Align
WKHÀRZDQGUHWXUQKHDGHUV
horizontally using the adjustable
feet.
2. Place the gas line in its intended
UHFHVV:KHQXVLQJVHYHUDOÀRZ
and return headers: Connect the
gas lines using the supplied DN65
gaskets, M12 bolts, spring washers
and nuts.
Fasten the gas line with the 2
special close tolerance bolts
0[[RQHDFKÀDQJHRIWKH
ÀRZDQGUHWXUQKHDGHUV
 )LWWKH/FROXPQVRQWKHÀDQJH
plate using 2-x bolt M8x110mm.
Attention: Use the correct holes
in the column!
 :KHQXVLQJDOHIWÀDQJHSODWH
use the right-hand holes in the
column.
 :KHQXVLQJDULJKWKDQGÀDQJH
plate: use the left-hand holes in
the column.
4. Fit a lower spacer on the front
of each L-column using 2-x bolt
M8x16mm.
Fit a lower spacer on the back
of each L-column using 2-x bolt
M8x16mm.
5. Fit the upper beam on each
L-column using 2-x bolt M8x50 mm.
6. Hang the boilers on the back
suspension Brackets.
For the lifting refer to “Lifting
and carrying precautions”
on page 18.
Continue with page 24.
6
1
okok
3
4
5
2
