Atag XL75W User Manual

27
Installation
Cascade accessories
'LPHQVLRQVKHDGHUVORZORVVKHDGHUVDQGEHQGV
Dimensions main header
DN65 / DN100
100
ø55
350
130
195
550
20
240
455
L 2/4 places = 1398mm (DN65/DN100)
L 3/6 places = 2098mm (DN65/DN100)
14073 228
441
680
330175
30
220
110
G1/2”
G3/8”
DN65
DN65
DN65
DN65
G1”
25080 349
709
910
560175
30
220
110
DN100
DN100
DN100
DN100
G1”
G1/2”
G3/8”
Dimensions low loss header DN65 up to 452kW
Dimensions low loss header DN100 up to 1000kW
DN65: 133
DN100: 197
DN65
DN100
Dimensions bend DN65 and DN100
