ATEQ F6 Profinet Series - Page 47

FG_F6_PROFINET_EN_04 / 2020-06-17
46 / 75
Identifier N°
Meaning
Value
Dec
Hexa
53
0035
“Press. UNIT”
Pressure unit.
Refer to Unit table.
60
003C
“Test FAIL”
Natural reject value of the test part
0 > 9999
61
003D
“TestREWORK”
Natural reject level of the test part in recovery
0 > 9999
62
003E
“Ref. FAIL”
Natural reject level of the reference part
0 > 9999
63
003F
“Ref.REWORK”
Natural reject value of the ref. part in recovery
0 > 9999
66
0042
“Set FILL”
Fill instruction value:
- 9999 > 9999
67
0043
“Set PreFILL“
Pre-fill instruction value:
- 9999 > 9999
68
0044
“SEALED PART”
Choice of the sealed component
Standard
Large Leak
0000
1000
72
0048
“Drift Unit”
Calibration drifts percent.
0 > 100%
80
0050
“Diff A-Z”
Differential auto reset time.
0 > 650 seconds
102
0066
“BLOW MODE”
Type of permanent blowing
Regulator 2
Regulator 1
0000
1000
103
0067
“FILL MODE”
Type of fill.
Standard
Instruction
Ballistic
Ramp
Adjust
Auto-Fill
Ramp 2
EASY
EASY Auto
0000
1000
2000
3000
4000
5000
6000
7000
8000
104
0068
“PreFILL”
Type of pre-fill.
Standard
Instruction
Ballistic
Ramp
EASY
EASY Auto
0000
1000
2000
3000
4000
5000
106
006A
“CheckTime”
Commutation time of the equalization valve
calibration check.
0 > 650 seconds
107
006B
“% Drift”
ATR absorption tolerance.
0 > 100%
108
006C
“Start”
Start value of the transient (ATR).
- 9999 > 9999
110
006E
“EXT. DUMP”
Type of external dump.
Normally close
Normally open
0000
1000
111
006F
“Ref. VOL.“
Reference volume.
0 > 9999
