FG_F6_PROFINET_EN_04 / 2020-06-17
‘IN7:”
Function attributed to the entry of the special
cycles (input 7)
Refer to the “Configurable input
values” table at the end of this
chapter
“Set Blow”
Permanent blowing pressure instruction.
“REJECT CALC.”
Original unit for the calculation of rejects in cm3/ min
(Pa, Pa/s...).
“Min Level” (Sealed Diff menu)
Minimum sealed component measurement pressure.
“Max Level” (Sealed Diff menu)
Maximum sealed component measurement pressure.
“FILL TIME”(Sealed Diff menu) Fill time of the internal
volume.
“TRANSFER”(Sealed Diff menu) Sealed component
transfer time.
“LANGUAGE”
Choice of the language.
Default language
2
nd
predefined
language
“Max Value”
Reject in calibration check.
“% Drift”
Percentage of the calibration check.
“Max PreFILL”
Maximum pressure value in pre-fill.
“Leak Rate”
Instruction value during a calibration.
“% of T FAIL”
Reject level percent of the auto parameter function
“FILL REG”
Regulator number selection for the fill.
“PRE FILL REG”
Regulator number selection for the pre-fill.
“CORRECTION” (TEMP.CORR. 1 menu)
Percentage concerning the temperature
compensation.
“TEST TIME”(TEMP.CORR. 1 menu)
Test time for the temperature compensation.
“Max FILL”
Max pressure in indirect test (piezo 2).
“Min FILL”
Min pressure in indirect test (piezo 2).
“OUTPUTS CONFIG.”
Setup of the outputs (standard or compact).
