ATEQ F6 Profinet Series - Page 49

FG_F6_PROFINET_EN_04 / 2020-06-17
48 / 75
Identifier N°
Meaning
Value
Dec
Hexa
161
00A1
“Volume UNIT”
Volume unit.
Refer to Unit table.
164
00A4
“NEXT PROG.”
Number of the following program in sequencing.
1 > 128
165
00A5
“N. OF CYCLES”(PIEZO AUTO AZ menu)
Number of cycles between two automatic reset.
0 > 9999
166
00A6
“N. OF MINUTES”(PIEZO AUTO AZ menu)
Time between two automatic reset.
0 > 999 minutes
175
00AF
“REGUL. CTRL.”
Regulator check during its learning.
Automatic
Ext
0000
1000
203
00CB
“ELEC. REG.”
Activation or not of the built in electronics
regulators.
None
Reg 1
Reg 2
ALL Reg
0000
1000
2000
3000
232
00E8
“ATR DRIFT”
Drift transient (ATR).
0 > 100%
233
00E9
“AZ SHORT”
Quick auto-zero time.
0 > 650 seconds
273
0111
“DUMP”
Dump time in calibration check mode
0 > 650 seconds
291
0123
“T.ATR2”
Stabilization time for the ATR 2 function
0 > 650 seconds
295
0127
“DUMP LEVEL”
Minimum dump pressure level to reach
- 9999 > 9999
297
0129
“MAX BLOW”
Blowing maximum pressure level
- 9999 > 9999
298
012A
“MIN BLOW”
Blowing minimum pressure level
- 9999 > 9999
315
013B
“Start FILL”
Start value of the fill instruction in burst test mode
- 9999 > 9999
334
014E
“RAMP”
Rise time in burst test mode
0 > 650 seconds
335
014F
“T. LEVEL”
Step time in burst test mode
0 > 650 seconds
336
0150
”N. OF STEPS”
Step number in burst test mode
0 > 650 seconds
340
0154
“Transient”
ATR transient value.
- 9999 > 9999
349
015D
“FILL TIME” (Indirect menu)
Fill time in recovery test mode
0 > 650 seconds
353
0161
“Press. UNIT” (configuration/pneumatic menu)
General pressure unit
Refer to Unit table.
354
0162
“LINE P. MIN”
Minimum line pressure level
- 9999 > 9999
355
0163
“FILL TIME” (AUTO VOL menu)
Internal volume fill time in program selection by
volume function
0 > 650 seconds
356
0164
“TRANSFER” (AUTO VOL menu)
Transfer time in program selection by volume
function
0 > 650 seconds
