Atlas Copco HB Series User Manual

Maintenance schedule
Monitor the filling level of the grease cartridge of the ContiLube
®
II lubrication system and
immediately replace an empty cartridge.
Monitor the lubricant film on the shaft of the working tool.
Manual lubrication of the working tool approx. every 2 hours.
during a shift
Check the hydraulic lines for leaks.
Check that the pipe clamps on the carrier are tight.
Check the screw connections of the swivel joint covers and tighten as required.
Replace damaged swivel joint covers.
daily
Tighten the screw connections daily during the first 50 operating hours.
Replace the oil filter cartridges after the first 50 operating hours.
Check the fill pressure of the HP-accumulator during the first operating week.
during and after the first 50 operating hours
Visual check of the tensioning bolts through the service openings placed at the top of the breaker
box's rear side.
Check the screw connections and tighten as required.
Check the pins in the retainer bars.
Check that the plugs of the retainer bars are in place and are not damaged.
Replace any damaged plugs.
Check the adapter plate and the breaker box for cracks.
In normal use:
Clean and grease the DustProtector system.
Check the connecting fittings of the ContiLube
®
II system for leaks.
weekly
Check the gas pressure in the piston accumulator monthly, and in cases of decreasing power
or failure of the hydraulic breaker.
monthly
Check the fill pressure of the HP-accumulator.after the first three operating month
Check the oil filter and replace as required.every 500 operating hours
Check the working tool for wear.
Check the lower and upper wear bush for wear.
Check that the piston impact surface is not chipped.
Check that the working tool impact surface is not chipped.
Check the working tool for burrs.
Check the retainer bar for burrs.
when replacing the working tool, and at
least every 100 operating hours
Check the fill pressure of the HP-accumulator.annual
Replace bent and damaged pipes.
Replace damaged hoses.
Check the pressure in the piston accumulator.
In case of dusty conditions:
Clean and grease the DustProtector system.
Check the adapter plate bolts for wear.
if necessary
© 2012 Atlas Copco Construction Tools GmbH | No. 3390 5005 01 | 2012-05-03
Original instructions
42
HB 5800, 5800 DP, 7000, 7000 DP, 10000 DPMAINTENANCE
