Apply anti-seize compound to the Allen screw threads before inserting them. The contact faces of the screw head
and the lock washers must not be lubricated.
*
1. Pre-tighten the tensioning bolts to 500 Nm crosswise,
2. retighten 120° (2 hexagons) crosswise,
3. retighten 180° (3 hexagons) crosswise
**HB 5800/DP
1. Pre-tighten the tensioning bolts to 500 Nm crosswise,
2. retighten 180° (3 hexagons) crosswise,
3. retighten 180° (3 hexagons) crosswise
**HB 7000/DP
1. Pre-tighten the tensioning bolts to 500 Nm crosswise,
2. retighten 120° (2 hexagons) crosswise,
3. retighten 120° (2 hexagons) crosswise,
4. retighten 150° (2.5 hexagons) crosswise
**HB 10000/DP
Tightening regulations for expansion bolts on HP-accumulator:
1. Treat the threads of the expansion bolts and the threaded inserts with Anti-Seize agent.
2. Treat the surfaces between the expansion bolt head, washer, and HP-accumulator cover with Anti-Seize agent.
3. Place on the HP-accumulator, and tighten the expansion bolts by hand in a crosswise fashion.
4. Pretighten the expansion bolts to
HB 5800/DP from SN 49 to 169 = 100 Nm
HB 5800/DP from SN 170 = 80 Nm
HB 7000/DP from SN 169 to 269 = 100 Nm
HB 7000/DP from SN 270 = 80 Nm
HB 10000/DP = 120 Nm, proceeding in a crosswise fashion.
5. Tighten each expansion bolt through 30° in a crosswise fashion.
6. Finally tighten each expansion bolt again through 60° in a crosswise fashion.
***
1. Treat the threads and threaded inserts for fixing screws with an Anti-Seize agent.
2. Treat the surfaces between the bolt head and the adapter plate with Anti-Seize agent.
3. Place on the adapter plate, and tighten the fixing screws by hand in a crosswise fashion.
4. Tighten the fixing screws to 600 Nm, proceeding in a crosswise fashion
****HB 5800/DP
© 2012 Atlas Copco Construction Tools GmbH | No. 3390 5005 01 | 2012-05-03
Original instructions
56
HB 5800, 5800 DP, 7000, 7000 DP, 10000 DPMAINTENANCE
