Parameter name Description Range/Values
Out OK Output for the OK signal for individual tightening oper-
ations.
---, OUT-1...OUT-6
Default: ---
Out NOK Output for the NOK signal for individual tightening op-
erations
---, OUT-1...OUT-6
Default: ---
Out complete OK Output for a job with all OK signals, that is, all posi-
tions successfully processed.
---, OUT-1...OUT-6
Default: ---
Out complete NOK Output for a job with all NOK signals, which indicate
that the job is cancelled.
---, OUT-1...OUT-6
Default: ---
Out Pset bit 1 Bit 1 of a Pset select value (0-8 bits possible)
Only valid for tool model = electrical
---, OUT-1...OUT-6
Default: ---
Out Pset bit 2 Bit 2 of a Pset select value (0-8 bits possible)
Only valid for tool model = electrical
---, OUT-1...OUT-6
Default: ---
Out Pset bit 4 Bit 3 of a Pset select value (0-8 bits possible)
Only valid for tool model = electrical
---, OUT-1...OUT-6
Default: ---
Out Pset bit 8 Bit 4 of a Pset select value (0-8 bits possible)
Only valid for tool model = electrical
---, OUT-1...OUT-6
Default: ---
Out Pset bit 16 Bit 5 of a Pset select value (0-8 bits possible)
Only valid for tool model = electrical
---, OUT-1...OUT-6
Default: ---
Out Pset bit 32 Bit 6 of a Pset select value (0-8 bits possible)
Only valid for tool model = electrical
---, OUT-1...OUT-6
Default: ---
Out Pset bit 64 Bit 7 of a Pset select value (0-8 bits possible)
Only valid for tool model = electrical
---, OUT-1...OUT-6
Default: ---
Out Pset bit 128 Bit 8 of a Pset select value (0-8 bits possible)
Only valid for tool model = electrical
---, OUT-1...OUT-6
Default: ---
Out I/O Rework Output for an additional signal, which interacts with the
OK output for individual tightening, but indicates that
there was a preceding skip/forward operation in that
job.
---, OUT-1...OUT-6
Default: ---
Sequence
Parameter name Description Range/Values
Label Defines how a job should be started when the TPS re-
ceives label information from a barcode scanner
allow start, change job, start job
Default: allow start
Start signal Selects between
■
Edge
To start a job, it is necessary to change from low
to high input signal
■
Level
Job always starts, when the input signal is high
■
Continuous
To start a job requires a rising edge. Also, the start
signal must be available during the entire opera-
tion (otherwise the operation will end)
Edge, Level, Continuous
Default: Edge
