User guide EN TPS Control
38
© Atlas Copco Industrial Technique AB - 9836 5819 01
Parameter name Description Range/Values
Debounce start Defines the start evaluation of flank/duration time in
0.1 seconds (the signal must be low to ensure that
flank is accepted).
Definition of start evaluation of condition:
forced interruption between the end of the last opera-
tion and the beginning of the new operation when the
start signal is always high
Off. 0.1-9.9 seconds
Default: Off
Start pause Sets the minimum duration of an interruption before a
new job can be started by the input.
Only visible if start signal = Level
Enable Backstep Enables the operator to go back to a previous position
and perform a procedure, even if the result of the pre-
vious operation was OK.
Off, On
Default: Off
Forward step Enables the operator to go forward one position after
using the Back button without completing the position
operation.
Off, On
Default: Off
NOK acknowledge Enables a tool to be released for the next operation in
the case that the previous position has returned an
NOK result.
Off, On
Default: Off
NOK max count Defines the maximum number of repeated attempts
per position when the Pset has returned an NOK re-
sult. If the number is exceeded, a signal will be issued
and the Pset will have to be reset.
Off, 1-99
Default: Off
NOK max acknowl-
edge
Defines the maximum number of times the NOK but-
ton can be pressed after the Pset has returned an
NOK result. If the number is exceeded, a signal will be
issued and the Pset will have to be reset.
Off, On
Default: Off
Max NOK's per job Defines the maximum number of NOK results in a job.
If the number is exceeded, a signal will be issued and
the Pset will have to be reset.
Off, 1-255
Default: Off
Clamp delay Defines how long clamping will be activated after start. 0.0-25.5 seconds
Default: 0.0
Clamp time close 0.0-99.9 seconds
Default: 0.0
Clamp time open 0.0-99.9 seconds
Default: 0.0
Clamp pulse time 0.0-99.9 seconds
Default: 0.0
Position timeout Defines the maximum amount of time that can be
spent in a position step.
Off, 1-99 seconds
Default: Off
Missing pos.qualifier Defines the system behaviour when the signal of a po-
sition query drops for more than 500 ms after being
available once.
■
hold
The system waits until the signal returns
■
abort
The system interrupts this cycle with NOK
hold, abort
Default: hold
