MARKINGS AND INFORMATION LABELS
Compressor outlet pressure
Compressor outlet temperature
Engine oil temperature
Engine oil pressure
Dangerous outlet gases.
Danger, hot surface.
Electrocution hazard.
Atlas Copco synthetic
compressor oil.
Manual.
Read the instruction manual
before working on the battery.
Reset fuse.
On / off button.
Hours, Time
compressor loaded
Prohibition to open air valves
without connected hoses.
Rotation direction.
Inlet.
Outlet.
Compressor oil drain.
Battery charge indication
Read the instruction manual
before starting.
Service every 24 hours.
Warning! Part under pressure.
Do not stand on outlet valves.
Start-Stop indication of switch.
Do not run the compressor
with open doors.
Lifting permitted.
Use diesel fuel only.
Fuel ON
Preheater
4.75 bar
(69 psi)
Tyre pressure.
Low Coolant
Read the instruction manual
before lifting.
Read the instruction manual
before topping up with coolant.
Service point.
Circuit breaker.
Horizontal towbar
possition required
in case of
coupling
