Atlas Copco XAHS 186 Cud PNE

- 61 -
PERFORMANCE DATA
At reference conditions, if applicable, and at normal shaft speed, unless otherwise stated.
Designation Unit XAHS 186 Cud
Engine shaft speed, normal and maximum r/min 2300
Engine shaft speed, compressor unloaded r/min 1200
Free air delivery
1)
without aftercooler l/s 181
cfm 384
with aftercooler l/s 176
cfm 373
Typical oil content of compressed air mg/m
3
free
air
3
oz/1000 cu.ft 0.003
Engine oil consumption (maximum) g/h 217.1
oz/h 7.66
Compressed air temperature at outlet valve without aftercooler °C Ambient + 65
°F Ambient + 149
with aftercooler °C Ambient + 12
°F Ambient + 54
Noise level
- Sound pressure level (LP), complies with ISO 2151 under free field conditions at
7 m distance
dB(A) -
- Sound pressure level (LP), complies with EPA under free field conditions at 7 m
distance
dB(A) 85
- Sound power level (LW) complies with 2000/14/EC dB(A) -
