- 32 -
STARTING / STOPPING
CONTROL PANEL
H1 LED (green) Fuel ON P1 Hourmeter
H2 LED (green) Preheat(option) F1 Circuit breaker button
H3 LED (red) Charge indication PG Working pressure guage
H4 LED (red) Compressor outlet temperature LV Loading valve
H5 LED (red) Engine oil temperature N4 Control module
H6 LED (red) Engine oil pressure S Start/Stop button
H7 LED (red) Low coolant
H8 LED (red) Not in use
