TORQUE VALUES
GENERAL TORQUE VALUES
The following tables list the recommended torques applied for
general applications at assembly of the compressor.
For hexagon screws and nuts with strength grade 8.8
For hexagon screws and nuts with strength grade 12.9
Thread size Torque value (Nm / lbf.ft)
M6 9 (6.64)
M8 23 (16.97)
M10 46 (34.69
M12 80 (59.04)
M14 125 (92.25)
M16 205 (151.29)
Thread size Torque value (Nm / lbf.ft)
M6 15 (11.07)
M8 39 (28.78)
M10 78 (57.56)
M12 135 (99.63)
M14 210 (154.98)
M16 345 (254.61)
Secure the drain cock and tank cap of the fuel tank
handtight
