Atmel AVR AT90CAN32

386
7679H–CAN–08/08
AT90CAN32/64/128
Figure 28-4. Active Supply Current vs. Vcc (Internal RC Oscillator 1 MHz)
Figure 28-5. Active Supply Current vs. Vcc (32 kHz Watch Crystal)
ACTIVE SUPPLY CURRENT vs. Vcc (Internal RC Oscillator 1 MHz)
0
0.5
1
1.5
2
2.5
3
2.5 3 3.5 4 4.5 5 5.5
Vcc (V)
Icc (mA)
85°C
25°C
-40°C
ACTIVE SUPPLY CURRENT vs. Vcc (32 kHz Watch Crystal)
0
20
40
60
80
100
120
140
2.5 3 3.5 4 4.5 5 5.5
Vcc (V)
Icc (uA)
25°C
