Atmel AVR AT90CAN32

389
7679H–CAN–08/08
AT90CAN32/64/128
Figure 28-10. Idle Supply Current vs. Vcc (32 kHz Watch Crystal)
28.3 Power-down Supply Current
Figure 28-11. Power-down Supply Current vs. Vcc (Watchdog Timer Disabled)
IDLE SUPPLY CURRENT vs. Vcc (32 KHz Watch Crystal)
0
10
20
30
40
50
60
2.5 3 3.5 4 4.5 5 5.5
Vcc (V)
Icc (uA)
25°C
POWER-DOWN SUPPLY CURRENT vs. Vcc (Watchdog Timer Disabled)
0
1
2
3
4
5
6
7
8
9
2.5 3 3.5 4 4.5 5 5.5
Vcc (V)
Icc (uA)
85°C
25°C
-40°C
