21. Analog to Digital Converter - ADC
21.1 Features
10-bit Resolution
0.5 LSB Integral Non-linearity
± 2 LSB Absolute Accuracy
65 - 260 µs Conversion Time
Up to 15 kSPS at Maximum Resolution
Eight Multiplexed Single Ended Input Channels
Seven Differential input channels
Optional Left Adjustment for ADC Result Readout
0 - V
CC
ADC Input Voltage Range
Selectable 2.56 V ADC Reference Voltage
Free Running or Single Conversion Mode
ADC Start Conversion by Auto Triggering on Interrupt Sources
Interrupt on ADC Conversion Complete
Sleep Mode Noise Canceler
The AT90CAN32/64/128 features a 10-bit successive approximation ADC. The ADC is con-
nected to an 8-channel Analog Multiplexer which allows eight single-ended voltage inputs
constructed from the pins of Port F. The single-ended voltage inputs refer to 0V (GND).
The device also supports 16 differential voltage input combinations. Two of the differential inputs
(ADC1, ADC0 and ADC3, ADC2) are equipped with a programmable gain stage, providing
amplification steps of 0 dB (1x), 20 dB (10x), or 46 dB (200x) on the differential input voltage
before the A/D conversion. Seven differential analog input channels share a common negative
terminal (ADC1), while any other ADC input can be selected as the positive input terminal. If 1x
or 10x gain is used, 8-bit resolution can be expected. If 200x gain is used, 7-bit resolution can be
expected.
The ADC contains a Sample and Hold circuit which ensures that the input voltage to the ADC is
held at a constant level during conversion. A block diagram of the ADC is shown in Figure 21-1.
The ADC has a separate analog supply voltage pin, AV
CC
. AV
CC
must not differ more than ±
0.3V from V
CC
. See the paragraph “ADC Noise Canceler” on page 280 on how to connect this
pin.
Internal reference voltages of nominally 2.56V or AV
CC
are provided On-chip. The voltage refer-
ence may be externally decoupled at the AREF pin by a capacitor for better noise performance.
