Atmel AVR AT90CAN32 User Manual

388
7679H–CAN–08/08
AT90CAN32/64/128
Figure 28-8. Idle Supply Current vs. Vcc (Internal RC Oscillator 8 MHz)
Figure 28-9. Idle Supply Current vs. Vcc (Internal RC Oscillator 1 MHz)
IDLE SUPPLY CURRENT vs. Vcc (Internal RC Oscillator 8 MHz)
0
2
4
6
8
10
12
14
2.5 3 3.5 4 4.5 5 5.5
Vcc (V)
Icc (mA)
85°C
25°C
-40°C
IDLE SUPPLY CURRENT vs. Vcc (Internal RC Oscillator 1 MHz)
0
0.2
0.4
0.6
0.8
1
1.2
1.4
1.6
1.8
2.5 3 3.5 4 4.5 5 5.5
Vcc (V)
Icc (mA)
85°C
25°C
-40°C
