ATN Zebra 16 Operator's And Safety Manual

OPERATOR AND SAFETY MANUAL
60
1NO0035UK-05
Zebra 16
GROUND COMMANDS STATUS (F3)
1- Entry parameters - Structure orientation.
2- Entry parameters - Arm 2.
3- Entry parameters - Arm 1.
The arrows light up when the corresponding movement is commanded.
Status light - Arm 2 position sensor (the light is on when the arm is in low
position).
The arrows light up when the corresponding movement is commanded.
Status light - Arm 1 position sensor (the light is on when the arm is in low
position).
The arrows light up when the corresponding movement is commanded.
Status light - Tower position sensor (the light is on when the tower is in the
axis).
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(9)
(10)
(8)
(12)
(11)
