ATN Zebra 16 User Manual

OPERATOR’S AND SAFETY HANDBOOK
1NO0060EN-00
Zebra 12 – Zebra 16
20
CHARACTERISTICS
Zebra 12
Zebra 16
Zebra 16 STAB
Maximum working height
12.20 m
16.40 m
16.80 m
Max floor height
10.20 m
14.40 m
14.80 m
Min floor height
0.37 m
0.40 m
Max outreach (A l’axe)
8.10 m
8.90 m
Max working outreach (A l’axe)
8.60 m
9.40 m
Structure orientation
360° (Not continuous)
Work platform rotation
2x 90°
Work platform dimensions
0.86 x 1.51 m
0.86 x 1.80 m
Max number of people on the platform
2
Platform capacity
230 kg
Max. admissible wind
12.5 m/s (45 km/h)
Max. manual force
400 Newton
Max. admissible tilt (On wheels)
4°
5°
Max. admissible tilt (On outriggers)
-
-
1°
Max. admissible slope
40%
45%
43%
Longitudinal levelling capacity
-
-
8° (14%)
Transversal levelling capacity
-
-
11° (19%)
Overall length (Transport position)
6.05 m
7.09 m
7.56 m
Overal length (Storage position)
4.50 m
5.09 m
5.56 m
Overall width
1.99 m
2.19 m
Overall height (Transport position)
2.60 m
2.22 m
Wheelbase
2.00 m
2.10 m
Ground clearance
0.37 m
0.40 m
Oscillating axle course
0.23 m (14°)
Number of driving wheels
4
Number of steering wheels
2
Tyres (solid tyres)
21x10-20
830x285(530)
Turning radius
Inner
1.72 m
Outer
4.28 m
4.55 m
4.88 m
Travel speed
Transport position
6 km/h
Platform raised
0.85 km/h
Empty weight
5 250 kg
7 110 kg
7 960 kg
Ground load on one
wheel (*)
Force
3 077 daN
4 200 daN
Contact pressure
13.0 kg/cm²
(1275 kPa)
14.5 kg/cm² (1422 kPa)
Ground load on one
outrigger (*)
Force
-
3 560 daN
Contact pressure
-
8.6 kg/cm² (6681 kPa)
(*) : The floor load values indicated may vary depending on the configuration/position of the
machine. An adequate safety margin with respect to these values should always be kept.
The weighted acoustic pressure level A on the platform's control station is 82 dB(A).
The weighted acoustic power level emitted by the machine (LWA) is 104 dB (test method according
to European directive 2000/14/CE relating to noise emissions in the environment of equipment
intended to be used outside buildings – Appendix III, Section B, Points 0 and 1).
The total value of the vibrations to which the hand-arm system is exposed does not exceed
2.5m/s².
The average maximum quadratic value weighted by the acceleration frequency to which the whole
body is exposed does not exceed 0.5m/s².
Due to constant improvements made to its products, ATN reserves the right to alter their
specifications and equipment without notice.
