ATN Zebra 16 User Manual

OPERATOR’S AND SAFETY HANDBOOK
1NO0060EN-00
Zebra 12 – Zebra 16
21
DUREES DES MOUVEMENTS
Zebra 12
Zebra 16
Arm 1
Elevation
Idle
16 to 18 seconds
29 to 32 seconds
High speed
17 to 20 seconds
Descent
Idle
16 to 18 seconds
24 to 27 seconds
High speed
21 to 24 seconds
Arm 2
Elevation
Idle
16 to 19 seconds
25 to 28 seconds
High speed
14 to 17 seconds
Descent
Idle
16 to 19 seconds
17 to 20 seconds
High speed
13 to 17 seconds
Arm 3
Elevation
17 to 19 seconds
16 to19 seconds
Descente
17 to 19 seconds
18 to 21 seconds
Telescope
Extension
Idle
11 to 13 seconds
30 to 33 seconds
High speed
17 to 20 seconds
Retraction
Idle
11 to 13 seconds
18 to 21 seconds
High speed
16 to 19 seconds
Orientation (end to end)
110 to 120
seconds
110 to 120
seconds
Rotation (end to end)
15 à 20 seconds
15 to 20 seconds
Note: The movement speeds may vary according to the telescope
position, the adjustment of the limit switches and the adjustment of
the load holding valves.
