• For storage, the overall length can be reduced by bringing the work platform under the
telescopic arm (Zebra 12) on the side of the arms (Zebra 16) :
Zebra 12:
1- Remove all material that may be in the work platform.
2- From the ground control station, slightly raise arm 2.
3- Use the platform levelling control to fold it under the arm making sure the platform
does not bump into the ground.
Zebra 16 :
1- Remove all material that may be in the work platform.
2- From the ground control station, lower arm 2, retract the telescope, turn the platform
at 90° to the right (until it stops).
3- Raise arm 1 as indicated below:
To Next Page
