Shenzhen AtomStack Technologies Co., Ltd. support@atomstack3d.com
3. Techniques for using machines
A. the closer the laser is to the table, the less stable the structure will
be, try to elevate the laser as far away from the table as possible
when using the laser.
B. The core spot of the laser is a 0.1*0.3mm rectangular spot, and
the width of the horizontal direction is 0.1mm, the length of the
vertical direction is 0.3mm. Carving Delicate models is
recommended to use the vertical direction.
C. Precise positioning of the pattern and the engraved object.
a. Move the laser to the lower left of the frame.
b. Using a ruler and pencil to draw a center point on the engraved
object.
Picture 3.1 draw a center point on the engraved object
c. The shield must be parallel to the edge of the engraved object.
Picture 3.2 The shield is parallel to the edge of the engraved object
d. Click on the following two buttons in sequence to move the laser
so that the laser point moves to the center of the engraving. Once
the positioning is complete, you can start engraving.
