Atronic e-motion - Diagnostics Folder for Hardware Tests

43
April 2007
e-motion™ Operating Manual - B-Level STD
Note:
See manual "Software / Basic
Setup" for a detailed
description of particular
Diagnostic Folder items.
SERVICE MENU
Diagnostics
Coin Handling
Hopper Out
Hopper Out All
Hopper Out Manually
Hopper Switch Test
Coin Diverter Test
Optics Test
Bills Enabled
Validator Test with Stacking
Validator T. without Stacking
Hopper 1
Hopper
Drop Box
Reject
A-Link Status
Bill Validator
Hopper
Other Tests
Toplight
Lamp
Switch
Button
Barcode Voucher
DIAGNOSTICS FOLDER
The diagnostics folder within the Service Menu
provides several in-machine hardware tests.
These tests are intended for regular maintenance and
trouble-shooting. Availability of some tests depends
on machine configuration (eg. A-Link status, barcode
voucher).
DIAGNOSTICS FOLDER FLOWCHART
