Body
Audi TT Quick Reference Specication Book • May 2009 95
Center Dimensions
Component mm
A 3.5 mm ± 0.5 mm
B 3.5 mm ± 0.5 mm
C 0 mm to -1 mm
D 0 mm to +1 mm
E 3.5 mm ± 0.5 mm
