02Q Manual Transmission Specications
Manual transmission
Code letters JLV JYV KDP
Manufactured from 04.06 11.06 06.07
to 11.06
Application Model Audi TT from
2007
Audi TT from
2007
Audi TT from
2007
Engine 3.2 L -
184 kW
3.2 L -
184 kW
3.2 L -
184 kW
Gear ratios Final drive I for
1st to 4th gear
72:17 =
4.235
72:17 =
4.235
72:17 =
4.235
Z2:Z1 = i Final drive II
for 5th/6th and
reverse gears
72:22 =
3.273
72:22 =
3.273
72:22 =
3.273
1st Gear 47:14 =
3.357
47:14 =
3.357
47:14 =
3.357
2nd Gear 48:23 =
2.087
48:23 =
2.087
48:23 =
2.087
3rd Gear 47:32 =
1.469
47:32 =
1.469
47:32 =
1.469
4th Gear 37:34 =
1.088
37:34 =
1.088
37:34 =
1.088
5th Gear 41:37 =
1.108
41:37 =
1.108
41:37 =
1.108
6th Gear 31:34 =
0.912
31:34 =
0.912
31:34 =
0.912
Reverse gear 34:23 x
14:14 =
3.990
34:23 x
14:14 =
3.990
34:23 x
14:14 =
3.990
itotal in top gear 2.985 2.985 2.985
Capacity in manual
transmission
2.3 liters
Capacity in bevel box 0.9 liters
Clutch mechanism Hydraulic
The following information can be found in the Electronic Parts Catalog (ETKA):
• Gear oil specication
• Bevel box axle oil specication
• Drive shaft anges allocation
• Clutch allocation
• Rear nal drive allocation
