Audi TT Platform 2009 - Passenger Protection - Tightening Torques; Interior Trim - Tightening Torques

102 Audi TT Quick Reference Specication Book • May 2009
Passenger Protection – Tightening Torques
Component Nm
Seatbelt to outer oor assembly anchorage point 55
Belt anchor bolt 55
Front seat belt height adjuster bolt 55
Belt latch to seat bolt 20
Automatic belt retractor bolt 55
Rear center 3-point seatbelt belt latch hex nut 55
Rear center lap belt bolt 55
Rear double belt latch bolt 55
Airbag control module J234 nuts 8
Passenger side airbag unit bolts 10
Side airbag bolts 10
Side head curtain airbag cap nuts 5
Front door crash sensor bolts 5
Rear wheel housing crash sensor bolts 7
Interior Trim – Tightening Torques
Component Nm
Instrument panel bolts 3
Instrument panel above tunnel bolts 8
Instrument panel aligning bolts 2
Footwell trim bolts 1.5
Instrument panel below heating or A/C mechanism (2
bolts)
9
Instrument panel tunnel area bolts 20
Instrument panel tunnel area nuts 18
Fuse holder bolts 2
Fuse holder nuts 18
Door trim handle molding area bolts 1.5
Door trim handle molding area (4 surrounding bolts) 2
Door mirror triangle cover bolt 2
Upper A-pillar and B-pillar trim airbag emblem bolt 4
B-pillar trim bolts 4
C-pillar trim nut 1.5
Side trim bolts 2
Rear lid trim handle recess bolts 2
Luggage compartment cover side storage compartment
bolts
1.5
Luggage compartment side trim bolts 8
Molded headliner bolts 2
