Audi TT Platform 2009 - Assembly Attachments Mounting - Tightening Torques

22 Audi TT Quick Reference Specication Book • May 2009
Assembly Attachments Mounting –
Tightening Torques
Component Nm
Generator to Engine bolt and nut 23
A/C compressor bolt 25
Pulley with divided tooth belt guard bolt 10 plus an
additional 90°
(¼ turn)
Divided tooth belt tensioner bolt 23
Upper toothed belt cover bolt 10
Camshaft gear to rear toothed belt cover bolt 50 plus an
additional 180°
(½ turn)
Rear toothed belt cover bolt 10
Semi-automatic tensioning roller to rear tooth belt cover
bolt
25
Damper roller to rear toothed belt cover bolt 25
Coolant pump bolt 15
Damper roller to sealing ange bolt 35
Crankshaft toothed belt gear to sealing ange bolt 90 plus an
additional 90°
(¼ turn)
Engine mount bolt 45
Knock Sensor (KS) 1 G61 bolt 20
Knock Sensor (KS) 2 G66 bolt 20
Oil lter bracket to engine bolt 15 plus an
additional 90°
(¼ turn)
Engine speed (RPM) sensor G28 to intake manifold
support to engine bolt
10
Coolant thermostat housing with coolant thermostat to
engine bolt
15
