68 Audi TT Quick Reference Specication Book • May 2009
02E Direct Shift Automatic Transmission
Capacities
Capacities 6-Speed Direct Shift Automatic Transmission 02E All
Wheel Drive
Initial lling 6.9L
Change Approximately 5.5L
02E Bevel Box Capacities
Capacities Bevel Box
Initial lling 0.9L
Change Filled for life, no change
Automatic Transmission Controls – 02E
02E Selector Mechanism – Tightening Torques
Component Nm
Selector lever and selector mechanism bolt with spring 3.5
Mounting bracket bolts 20 plus an
additional 90°
(¼ turn)
Shift housing nuts 9
Selector lever and selector mechanism hex bolt with
washer
8
Selector lever cable adjustment bolt (02E) 13
02E Selector Shaft – Tightening Torques
Component Nm
Selector shaft lever to transmission 20
02E Transmission Input Speed (RPM) Sensor
G182 and Clutch Oil Temperature Sensor G509 –
Tightening Torques
Component Nm
Sensor 10
