Control Arm – Tightening Torques
Threaded connection Thread Nm
To console M12 x 1.5 x 110 70 plus an
additional 180°
(½ turn)
To ball joint M10 60
Mounting bracket to body M12 x 1.5 x 90 70 plus an
additional 90°
(¼ turn)
Mounting bracket to console M10 x 76 50 plus an
additional 90°
(¼ turn)
Left front level control system sensor
G78
M6 9
Stabilizer Bar – Tightening Torques
Threaded connection Thread Nm
To subframe M8 x 80 70 plus an
additional 90°
(¼ turn)
To coupling rod M12 65
Coupling rod to suspension strut M12 65
Pendulum Support – Tightening Torques
Threaded connection Thread Nm
To subframe M14 x 1.5 x 70 100 plus an
additional 90°
(¼ turn)
To transmission M10 x 35 40 plus an
additional 90°
(¼ turn)
M10 x 75 40 plus an
additional 90°
(¼ turn)
Suspension Strut – Tightening Torques
Threaded connection Thread Nm
To body M8 x 26 15 plus an
additional 90°
(¼ turn)
To wheel bearing housing M12 x 1.5 x 80 70 plus an
additional 90°
(¼ turn)
Strut mounting to piston rod M14 x 1.5 60
