skate control dial to have the same value as the tracking force value.
• The standard tracking force value for the cartridge provided with this product is 3.0 g.
Installing/removing the dust cover
The dust cover is designed to protect the product’s sensitive components when the product is not in use. It should remain off while records are playing.
Using the dust cover during play may result in record damage or sound degradation.
Always remove and replace the dust cover carefully.
Preparation for use
Setting pre-amplifier selector switch
This product has a built-in phono equalizer function. You can use the product, even if you do not have a phono amplifier or connectable equipment with a built-in phono amplifier, by
connecting an active speaker, etc. Use the pre-amplifier selector switch to set the output, as shown below.
Connectable equipment being used
Position of pre-amplifier selector
switch
Where to connect the RCA audio cable
Device with phono input PHONO Phono input jack and ground (earth) terminal of connectable equipment
Device without phono input LINE AUX or line input jack of connectable equipment
PC sound card LINE Sound card’s line input jack*1
Device with USB input LINE USB input of your computer*2
*1 An audio adapter (sold separately) may be required to connect the RCA audio cable to the PC sound card’s line input jack.
*2 Use included USB cable instead of RCA audio cable to connect.
Connecting to connectable equipment (active speakers, amplifiers, DJ mixer, etc.)
Connecting to audio source
Align the settings for the pre-amplifier selector switch and connect the RCA audio cable to an input jack that is compatible with the connectable equipment you are using (amplifier, receiver,
active speakers, sound card, etc.). The RCA audio cable’s red jack is for the right (R) channel, and the white jack is for the left (L) channel.
To Next Page
